| Repair
Coupler |
 |
Connects two lengths of soil
pipes. |
| • |
| Bend
87.5° |
|
Connects
two lengths of soil pipes. |
| • |
| Door
Bend 87.5° |
|
Gives 87.5° door with access
on the top side, for cleaning
purpose. |
| • |
| Reducer |
|
Connects 110 mm O.D. pipe to
75 mm O.D. pipe. |
| • |
| Bend
45° |
|
Used for giving 45° turn
to the line. Also used as shoe
for rainwater drainage line. |
| • |
| Double
Y |
|
Connects 2 branch lines at 45° |
| • |
| Single
Y |
|
Connects branch lines at 45° |
| • |
| Double
Y with Door |
|
Access is provided at the center
for cleaning. |
| • |
| Single
Y with Door |
|
Access is provided for cleaning. |
| • |
| Single
Tee |
|
Connects branch line at 87.5° |
| • |
| Single
Tee with Door |
|
Door is provided at 92.5° |
| • |
| Pipe
Clip |
|
Secures pipes on the flat surface. |
| • |
| Vent
Cowl |
|
Caps the upper end of the vent. |
| • |
| Double
Tee (4 ways) |
|
Connects 2 branch line at 87.5° |
| • |
| Cleansing
pipe |
|
In cleansing pipe, threaded
cap/door is provided for extra
cleaning. It can be used in
rain water as well as sewerage
line. |
| • |
| Double
Tee with Door |
|
Door is provided at 92.5° |
| • |
| W.C.
Connector |
|
W.C. Connectors are used to
drain out the waste from W.C.
pan. |
| • |
| Multi
Floor Trap |
|
Multi floor Trap is used for
removing water from bathrooms,
kitchen and basin through one
single line. |
| • |
| P-
Trap |
|
Where inlet and outlet are at
right angle to each other. |
| • |
| Q-
Trap |
|
Where
the outlet is at 45° to
inlet. |
| • |
| S-
Trap |
|
Where inlet and outlet are parallel
to each other. |
| • |
| Nani
Trap |
|
The Nani
Trap exactly replaces the conventional
type C. I. Nani trap. It provides
an easy flow of waste water
and requires minimum maintenance.
It maintains a standard water
level. A round jali is placed
directly. The Nani Traps are
available in 2 sizes-3"
and 4".
|
